Model #: IQ7X-96-2-US

The high-powered smart grid-ready Enphase IQ 7X Micro™ dramatically simplifies the installation process while achieving the highest
system efficiency for systems with 96-cell modules.

Part of the Enphase IQ System, the IQ 7X Micro integrates with the Enphase IQ Envoy™, Enphase IQ Battery™, and the Enphase Enlighten™ monitoring
and analysis software.

The IQ Series Microinverters extend the reliability standards set forth by previous generations and undergo over a million hours of power-on testing,
enabling Enphase to provide an industry-leading warranty of up to 25 years.

 Easy to Install
• Lightweight and simple
• Faster installation with improved, lighter two-wire cabling
• Built-in rapid shutdown compliant (NEC 2014 & 2017)
Efficient and Reliable
• Optimized for high powered 96-cell* modules
• Highest CEC efficiency of 97.5%
• More than a million hours of testing
• Class II double-insulated enclosure
• UL listed
Smart Grid Ready
• Complies with advanced grid support, voltage and
frequency ride-through requirements
• Remotely updates to respond to changing
grid requirements
• Configurable for varying grid profiles
• Meets CA Rule 21 (UL 1741-SA)

* The IQ 7X is required to support 96-cell modules

Technology: Micro-Inverter
Dimensions: 8.35 x 6.89 x 1.19 Inches
Weight: 2.38 lbs
Connector Type: MC4 (or Amphenol H4 UTX with Additional Q-DCC-5 Adapter)
Cooling: Natural convection - No Fans
Approved for Wet Locations: Yes
Pollution Degree: PD3
Enclosure: Class II Double-Insulated, Corrosion Resistant Polymeric Enclosure
Environmental Category / UV Exposure Rating: NEMA Type 6 / Outdoor
Communication: Power Line Communication (PLC)
Monitoring: Enlighten Manager and MyEnlighten Monitoring Options. Compatible with Enphase IQ Envoy
Disconnecting Means: The AC and DC Connectors Have Been Evaluated and Approved by UL for Use as the Load-Break Disconnect Required by NEC 690
Ambient Temperature Range: -40°C to +65°C
Relative Humidity Range: 4% to 100% (Condensing)

Electrical Information

Input Data
Commonly Used Module Pairings: 320W to 460W+
Module Compatibility: 96-Cell PV Modules
Maximum Input DC Voltage: 80 Volts
Peak Power Tracking Voltage: 53V-64 Volts
Operating Range: 25V-80 Volts
Min / Max Start Voltage: 30V / 80 Volts
Max DC Short Circuit Current (Module Isc): 10 Amps
Overvoltage Class DC Port: II
DC Port Backfeed Under Single Fault: 0 Amps
PV Array Configuration: 1 x 1 Undergrounded Array; No Additional DC Side Protection Required; AC Side Protection Requires Max 20A per Branch Circuit

Output Data

Peak Output Power: 320 VA
Maximum Continuous Output Power: 315 VA
Nominal Voltage / Range: 240V / 211-264V
Nominal Output Current: 1.31 Amps
Nominal Frequency: 60 Hz
Extended Frequency Range: 47-68 Hz
Maximum Units per 20 A (L-N) Branch Circuit: 12 (240 VAC)
Overvoltage Class AC Port: III
AC Port Backfeed Current: 0 Amps
Power Factor Setting: 1.0
Power Factor (Adjustable): 0.7 Leading ... 0.7 Lagging
Efficiency: 97.5%
